Steel Belt Cooler
REBO steel belt cooler uses a continuously rotating steel belt as its core conveying medium. It applies precise pressure through upper and lower pressure rollers, while adjusting the material forming temperature by means of a temperature control system, ensuring the material maintains an appropriate temperature and uniform density. In terms of output performance, this equipment adopts a continuous operation design, combined with adjustable steel belt running speed and wider pressure rollers, enabling higher output per unit. It can directly meet the daily production capacity requirements of large and medium-sized powder coating factories. Additionally, while ensuring high output, the equipment also balances production environmental friendliness and operational convenience.
Any questions?
Your Rebo technical advisor is here to help!
Highlights



*Equipped with a wide-width steel belt: Expands the single processing range and helps increase output.



*Adopts continuous operation design: Long continuous operation time improves operational efficiency.



*Stable temperature control system: Flexibly adjusts material temperature and maintains suitable processing state.



*Multiple safety protection devices: E.g., emergency stop, steel belt deviation check, to lower safety risks.



*Steel belt running speed is adjustable and stable: Can adapt to different processing rhythms according to production needs.



*Supports linkage control: Connects front/back-end control systems for coordinated operation.

Technical Data
Model Output(kg/hr) Belt Effective Length(mm) Belt Effective Width(mm) Squeezing/Conveying
Crushing Power(kW)
Extrusion Roller
Diameter(mm)
Dimension(mm)
RBCC100/50 600 6000 1000 1.1/1.1/1.1 418/240 7375x1700x1800
RBCC100/60 800 7000 1000 1.1/1.1/1.1 418/240 8375x1700x1800
RBCC100/70 1000 8000 1000 1.1/1.5/1.1 418/240 9375x1700x1800
RBCC120/50 800 6000 1200 1.5/1.5/1.5 418/240 7375x1900x1800
RBCC120/60 1000 7000 1200 1.5/1.5/1.5 418/240 8375x1900x1800
RBCC120/70 1200 8000 1200 1.5/2.2/1.5 418/240 9375x1900x1800
RBCC150/50 1000 6000 1500 2.2/2.2/2.2 418/240 7375x2200x1800
RBCC150/60 1250 7000 1500 2.2/2.2/2.2 418/240 8375x2200x1800
RBCC150/70 1500 8000 1500 2.2/2.2/2.2 418/240 9375x2200x1800
Explore Applications
  • Chemical industry
  • Resins(Epoxy, Polyester etc)
  • Adhesives
  • Aditives and pigments, Phenolic resins, Acrylic Resins, Polyamide Resins
  • Polyester resins
  • Others
