Steel Belts For Film Casting Industry
Film casting is widely used in the production of packaging plastic film, filter film and multi-functional plastic film, laundry beads, composite printing flexible packaging and other fields.
Model：RAT1200 / RAT1000 / RMT1650 / RMT1050
Steel Type：Stainless Steel
Tensile strength（Mpa）：1200 / 1000 / 1620 / 1150
Yield strength（Mpa）：980 / 780 / 1600 / 1120
Fatigue Strength（Mpa）：470 / 400 / 630 / 500
Hardness（HRC）：36±1 / 32±1 / 48±1 / 38±1
Elongation（%）：20 / 6 / 4-6 / 7-9
Weld factor：0.70 / 0.70 / 0.80 / 0.80
Film casting is widely used in the production of packaging plastic film, filter film and multi-functional plastic film, laundry beads, composite printing flexible packaging and other fields; high standards, high quality, and special processing can meet the requirements of the film casting industry for mirror-finished steel belt products. strict requirements.
RAT1200 Austenitic stainless steel belt
RAT1000 Austenitic stainless steel belt
RMT1650 Low carbon martensitic precipitation hardening stainless steel belt
RMT1050 Martensitic stainless steel steel belt
●Tensile strength（Mpa）：1200 / 1000 / 1620 / 1150
●Yield strength（Mpa）：980 / 780 / 1600 / 1120
●Fatigue Strength（Mpa）：470 / 400 / 630 / 500
●Hardness（HRC）：36±1 / 32±1 / 48±1 / 38±1
●Elongation（%）：20 / 6 / 4-6 / 7-9
●Weld factor：0.70 / 0.70 / 0.80 / 0.80
|
Model |
Length |
Width |
Thickness |
|
RAT1200 |
≤150 m |
600~2000 mm |
0.6 / 0.8 / 1.0 / 1.2 mm |
|
RAT1000 |
600~1550 mm |
0.6 / 0.8 / 1.0 / 1.2 mm |
|
|
RMT1650 |
600~1550 mm |
0.8/1.0/1.2/1.6/1.8/ … mm |
|
|
RMT1050 |
600~1550 mm |
0.8/1.0/1.2/1.6/1.8/ … mm |
- Packaging plastic film
- Filtration membrane
- Multi-functional plastic film
- Laundry condensate beads
- Composite printing flexible packaging
- Others
